Baja MarineOwner’s Manual202 IslanderOwner’s Manual Part Number: MRP 1811974© Baja Marine Corporation 2006RSpeed changes you.TM.

viii202 Islander® Information in this publication is based upon the latest product specications available at printing. Baja® Marine Corporation reser

202 Islander®1.1seCtIon 1 • saFetySAFE boating means:• Knowing the limitations of your boat• Following the "Rules of the Road"• Keeping a

202 Islander®1.2seCtIon 1 • saFety2. leGallY ManDaTeD MiniMuM requireD equipMenTThe following equipment is the minimum required by the U.S. Coast Gua

202 Islander®1.3seCtIon 1 • saFetySymptoms of carbon monoxide poisoning are dizziness, ears ringing, headaches, nausea, and unconsciousness. Get fres

202 Islander®1.4seCtIon 1 • saFetyEven strong swimmers can tire quickly in the water and drown due to exhaustion, hypothermia, or both. The buoyancy

202 Islander®1.5seCtIon 1 • saFetyDrugs and/or alcohol impair the operator's ability to control the boat safely.Death or serious injury ca

202 Islander®1.6seCtIon 1 • saFetyWhen engine is running, keep passengers away from areas not designed for riding, such as seat backs, bow, gunwales,

202 Islander®1.7seCtIon 1 • saFetyDeath or serious injury can result if you fail to observe these safety rules:• Anyone who controls the boat must h

202 Islander®1.8seCtIon 1 • saFetyThe wind speed and wave height specied as the upper limit for your category of boat does not mean that you or your

202 Islander®1.9seCtIon 1 • saFetyShut engine off if an object is struck or if you run aground.Check for hull leaks and propulsion system damage, be

Baja MarIne CorporatIon, 2600 sea ray Blvd., KnoxvIlle, tn 37914For InForMatIon Call 1-865-971-6270 or Fax 1-865-971-6716Internet address: http://www

202 Islander®1.10seCtIon 1 • saFetySKIING SIGNALS (FIG. 1.10.1)DIVERS FLAGS(FIG. 1.10.2)CODE ALPHAFLAGSPORT DIVER'SFLAGREDWHITEBLUEWHITETurn - Ar

202 Islander®1.11seCtIon 1 • saFetya. MeDical eMerGencYYou may be far from professional medical help when you are boating. At least two people on bo

202 Islander®1.12seCtIon 1 • saFetye. collisions anD leakinGIn the event of collisions and leaking:• Slow down or stop to reduce water intake, unles

202 Islander®1.13seCtIon 1 • saFety! WARNINGA wide variety of components used on this vessel contain or emit chemicals known to the St

202 Islander®1.14seCtIon 1 • saFetyNOTICEIt is illegal for any vessel to dump plastic trash anywhere in the ocean or navigable waters of the United St

202 Islander®1.15seCtIon 1 • saFety20. nauTical TerMsAbeam – object 90 degrees ( 90°) to center line on either side of boat.Abaft – a point on a boat

202 Islander®1.16seCtIon 1 • saFety21. keY To sYMbols on conTrols & prinTsThese symbols may be found on your controls and gauges and/or used in t

202 Islander®1.17RSpeed changes you.TM.22. WarninG label locaTionswarnIng laBel loCatIons(FIg 1.17.1)Located in Owner’s PacketCalifornia Residents On

202 Islander®1.18RSpeed changes you.TM.THIS PAGE INTENTIONALLY LEFT BLANK

202 Islander®2.1seCtIon 2 • general Boat arrangeMent! CAUTIONDo Not use cleats for lifting.2. passenGer locaTions1. When the boat is moving, all pa

i202 Islander®welCoMeCongratulations on becoming the new owner of the world’s #1 performance boat. Baja® Marine Corporation welcomes you

202 Islander®2.2seCtIon 2 • general Boat arrangeMent3. basic boaT DiMensions anD clearances (uniTeD sTaTes sTanDarD s.a.e.)202 Islander specificaTion

202 Islander®2.3seCtIon 2 • general Boat arrangeMentbasic boaT DiMensions anD clearances (MeTric)Boat dIMensIons and ClearanCes(FIg. 2.3.1)202 Islande

202 Islander®2.4seCtIon 2 • general Boat arrangeMent6. General Deck laYouTGENERAL DECK LAYOUT(FIG. 2.4.1)FWDREAR(AFT)LEFT(PORT)RIGHT(STBD)Navigation

202 Islander®2.5seCtIon 2 • general Boat arrangeMent7. DescripTion of Major conTrolsa. Gear shifT anD ThroTTle conTrolThe shift/throttle control uni

202 Islander®2.6seCtIon 2 • general Boat arrangeMentc. Trailer sWiTchThe trailer switch (Power Tilt) is not to be confused with the Power Trim functi

202 Islander®2.7seCtIon 2 • general Boat arrangeMentThe alarm indicates a problem with engine water temperature, oil pressure and/or stern drive

202 Islander®2.8seCtIon 2 • general Boat arrangeMentInsertIng the aFt reMovaBle navIgatIon/anChor lIght (loCated at the stern oF the Boat) (FIg 2.8.1)

3.1202 Islander®seCtIon 3 • usIng your Boat1. pre-launch, launch anD posT-launch checklisTListed below are the critical items you must check and do e

3.2seCtIon 3 • usIng your Boat202 Islander®3. fuelinG The boaTThe fuel ll cap is located on the port side of the boat (Figure 3.2.1). Do not mistake

3.3202 Islander®seCtIon 3 • usIng your Boat• Shut off gas burning appliances (gas stove, etc.).• Close all hatches, doors, and keep engi

ii202 Islander® THIS PAGE INTENTIONALLY LEFT BLANK

3.4seCtIon 3 • usIng your Boat202 Islander®• If there are passengers not wearing PFDs, the PFDs must be readily accessible. “Readily accessible

3.5202 Islander®seCtIon 3 • usIng your Boatit is recommended that the bilge blower run all the time the engine is running.6. Place drive unit in full

3.6seCtIon 3 • usIng your Boat202 Islander®10. sTeerinG sYsTeMsYour Baja® may be will be equipped with one of two types of steering. Please

3.7202 Islander®seCtIon 3 • usIng your Boatb. poWer sTeerinGThe power steering system is an enclosed push-pull cable that is hydraulically assisted (

4.1202 Islander®seCtIon 4 • BIlge & underwater gear1. bilGea. fuel & oil spillaGeRegulations prohibit discharging fuel or oily waste in navi

4.2202 Islander®seCtIon 4 • BIlge & underwater gearExcept for checking the operation of the bilge pump using the ON position, leave the switch in

4.3202 Islander®seCtIon 4 • BIlge & underwater gearc. iMpacT To sTern DriveThe stern drive can be damaged by impact, either while trailering or b

4.4202 Islander®seCtIon 4 • BIlge & underwater gearf. Install the thrust washer, propeller, continuity washer, thrust hub, propeller nut ret

202 Islander®5.1seCtIon 5 • Fuel systeM1. fuel sYsTeMSection 3 • Using Your Boat contains important fueling information. Take time to read all

202 Islander®5.2seCtIon 5 • Fuel systeM2. fuelinG precauTionsCertain precautions must be carefully and completely observed every time a boat is

iii202 Islander®IntroduCtIon1. This ManualThe material within this manual and your Owner’s Manual Packet:• Gives you basic safety information• Desc

202 Islander®5.3seCtIon 5 • Fuel systeM• Electrical equipment, including blowers – power off.• Doors, hatches – closed.• Smoking material – extingu

202 Islander®5.4seCtIon 5 • Fuel systeMTHIS PAGE INTENTIONALLY LEFT BLANK

202 Islander®6.1RSpeed changes you.TM.seCtIon 6 • eleCtrICal systeMs1. elecTrical sYsTeMs DirecT currenT (Dc)The 12 volt direct current (DC) el

202 Islander®6.2seCtIon 6 • eleCtrICal systeMsRSpeed changes you.TM.Protective terminal covers, such as rubber boots on electrical connections, mus

202 Islander®6.3seCtIon 6 • eleCtrICal systeMsRSpeed changes you.TM.Zinc anodes require replacement about every six months, if the boat is operat

202 Islander®6.4seCtIon 6 • eleCtrICal systeMsRSpeed changes you.TM.IgnItIon swItCh (FIg. 6.4.1)TO ENGINERUN CIRCUIT16 AWGPURPLE/BLACK16 AWGPURPLE/BLA

202 Islander®6.5seCtIon 6 • eleCtrICal systeMsRSpeed changes you.TM.TRAILER TRIMBLUE/WHITEREDGREEN/WHITE14 AWG RED14 AWG GREEN14 AWG BLUE14 AWG PURPLE

202 Islander®6.6seCtIon 6 • eleCtrICal systeMsRSpeed changes you.TM.THIS PAGE INTENTIONALLY LEFT BLANK

6.7202 Islander®RSpeed changes you.TM.swItCh panel wIre InForMatIon (FIg 6.7.1)#1#2#3#4PLUG 18 - Way Deutsch DT Series ReceptacleReceptacle DT

6.8202 Islander®RSpeed changes you.TM.dC wIre InForMatIon (FIg 6.8.1)

iv202 Islander® 6. hull iDenTificaTion nuMber (hin)The “Hull Identication Number” located on the starboard side of the transom, is the most im

202 Islander®7.1seCtIon 7 • optIons & aCCessorIes1. opTions & accessories locaTionsFigure 7.1.1 shows the location of some of the components.

202 Islander®7.2seCtIon 7 • optIons & aCCessorIes2. auToMaTic fire exTinGuisher sYsTeM (opTion)The 202 Islander may be equipped with an au

202 Islander®7.3seCtIon 7 • optIons & aCCessorIesFor safety and ease of installation and removal of canvas, use at least two people.The following

202 Islander®7.4seCtIon 7 • optIons & aCCessorIesREFER TO OWNER'S MANUAL PACKET FOR INSTRUCTIONS AND WARRANTY INFORMATION ON DEPTH FINDER

8.1202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCeITEMREQUIREDMAINTENANCE/SERVICEREFERENCE SOURCE BEFOREEVERY USEAFTER FIRST2

8.2 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCesuMMarY GuiDe for inspecTion, service anD MainTenance*Use in salt water or

8.3202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe2. useful service inforMaTionOWNERHOME PORTBOAT NAMEREGISTRATION NUMBER

8.4 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe3. inspecTion, service anD MainTenance proTocola. bilGe areaMany of your

8.5202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe• Check your rst aid kit, making certain it is complete and tha

8.6 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe5. fiTTinG ouT afTer sToraGea. fuel sYsTeMCheck the entire fuel system f

v202 Islander®RSpeed changes you.TM.abouT Your express liMiTeD WarranTYBaja Marine offers an Express Limited Warranty on each new Baja purchased throu

8.7202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe• Check fuel lines for damage and/or leaks. Make sure that they do not

8.8 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe8. quick reference checklisTAs the owner/operator of a Baja® Boat, you ar

8.9202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCequick reference checklisT (conT’D)*If engine fails to start, refer to the E

8.10 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCec. DeparTinGGeneral 1. Passengers/Crew ...

8.11202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCequick reference checklisT (conT’D) 3. Ignition ...

8.12 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe9. afTer MarkeT equipMenT checklisTAny safety or operational equipment a

8.13202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCe10. MainTenance loGFollow the recommended maintenance listed on pages 1 &

8.14 202 Islander®seCtIon 8 • requIred InspeCtIon, servICe, & MaIntenanCeMainTenance loG (conT’D) Date Maintenance Description Engine Hours

9.1202 Islander®seCtIon 9 • Care & reFInIshIngYour new boat has been designed to provide you with years of enjoyment and satisfaction. In order to

9.2seCtIon 9 • Care & reFInIshIng202 Islander®• Minor scratches and deeper stains that do not penetrate the gelcoat may be removed by light sandi

vi202 Islander® 202 Islander owner’s Manual • taBle oF ContentsinTroDucTion1. This Manual ...

9.3202 Islander®seCtIon 9 • Care & reFInIshIngThe fabric should be cleaned regularly before substances such as dirt, pollen, etc. are a

9.4seCtIon 9 • Care & reFInIshIng202 Islander®This Page inTenTionally lefT Blank

index202 islander®IndexAAccessories. See Options & Accessories LocationsBBilge 4.1Blower 4.2Maintenance 4.2, 8.4Pump 4.1Boarding 3.3Breaker

index 202 islander®This Page inTenTionally lefT Blank

vii202 Islander®secTion 5 • fuel sYsTeM1. Fuel System...............5.12. Fueling Precautions ....
